TD
PK
8431390000
● Provided with specially designed mechanical belt joint for connecting the belt
● Liner plate is provided to prevent wear and abrasion performance as per requirement
● Can be integrated to a combined system with other machinery
● Almost all floury and small-sized bulk materials can be handled in belt bucket elevator
● Backstop is be provided to prevent buckets reversal when shut down in emergency
● Heat-resistant rubber belt is provided to withstand high temperature material up to 200 ℃
● The lifting height can reach a maximum figure of 40m to meet different demand
| TD Belt Bucket Elevator | ||||||||||||
| Model | TD160 | TD250 | TD315 | TD400 | TD500 | TD630 | ||||||
| Bucket type | Zd | Sd | Zd | Sd | Zd | Sd | Zd | Sd | Zd | Sd | Zd | Sd |
| Capacity (m3/h) | 16 | 27 | 38 | 59 | 42 | 67 | 68 | 110 | 96 | 154 | 148 | 238 |
| Bucket width(mm) | 160 | 160 | 250 | 250 | 315 | 315 | 400 | 400 | 500 | 500 | ||
| Bucket volume(L) | 4.2 | 1.9 | 3.0 | 4.6 | 3.8 | 5.8 | 5.9 | 9.4 | 9.3 | 14.9 | 14.6 | 23.5 |
| Running Speed （m/s） | 1.4 | 1.6 | 1.6 | 1.8 | 1.8 | 2.0 | ||||||
| Hopper Spacing(m) | 350 | 450 | 500 | 560 | 625 | 710 | ||||||
| Pulley Rotation Speed | 67 t/min | 61 t/min | 61 t/min | 55 t/min | 55 t/min | 48 t/min | ||||||
| Belt Width (mm) | 200 | 200 | 300 | 300 | 400 | 400 | 500 | 500 | 600 | 600 | 700 | 700 |
